Lever Action Flushbolts Radiused Forend 300x20mm Satin Stainless Steel
The Frelan JSS52R radius-end stainless steel flush bolt (300mm) delivers discreet, lever-action security for the inactive door leaf while complementing contemporary, rounded-edge hardware suites in commercial interiors.
KEY FEATURES:
Concealed Design: Flush edge mount for refined sightlines.
Finish: Satin Stainless Steel.
Certification: BS EN 12051
Corrosion Grade: 4
Fire Resistance: FD30/60
Fittings Included: Keep, 4 x Wood Screws.
Use: Suitable for Commercial settings.
Profile: Radius
Flush Bolts: Lever Action
Mechanical Warranty: 10 years
DIMENSIONS
Length: 300mm
Dia. Bolt: 11mm
Bolt Throw: 15mm
To maintain compliance with the fire standard for these flush bolts, it is recommended that you fit these with the relevant intumescent pack (GRA 7 & GRA 8).
STANDARDS & CERTIFICATIONS
| Internal/External | Internal |
|---|---|
| Mechanical Warranty | 10 Years |
| Fixings Included | Keep, 4 x Wood Screws |
| PVD Finish | No |
| Overall Size | 300 x 20mm |
| Residential/Commerical | Residential/Commerical |
| Material Grade | 304g Stainless Steel |
| Range | Stainless Steel |
| Profile | Radiused Forend |
| Material | Stainless Steel |
| Finish | Satin Stainless Steel |
| Corrosion Grade | Grade 4 |
| Fire Rating | FD30/60 |
| Size | 300 x 20mm |
